STC-8000VA
STC-8000VA
Data Sheet Product
| MODEL | STC-8000VA |
| CAPACITY | 8000 VA |
| INPUT VOLTAGE | AC 95V-250V |
| ACTUAL WORKING INPUT VOLTAGE | 85-268V (AC) |
| INPUT VOLTAGE TO MAINTAIN HIGH PRECISION OUTPUT | 100-250V (AC) |
| OUTPUT VOLTAGE | AC 220V±5% 50/60Hz |
| DELAY TIME | Short Delay: 5sec Long Delay: 200sec |
| PROTECTION | Over Voltage, Under Voltage, Overload, High Temperature, Short Circuit |
| EFFICIENCY | >95% |
| PRODUCT SIZE (LxWxH) | 48.3×36.4×18.7 cm |
| PACKING SIZE | 49×39.5×23 cm |
| PCS/CARTON | 1 |
| N.W.(KGS) | 21 kg |
| G.W.(KGS) | 22.5 kg |
