STC-5000VA
STC-5000VA
Data Sheet Product
| MODEL | STC-5000VA |
| CAPACITY | 5000 VA |
| INPUT VOLTAGE | AC 95V-250V |
| ACTUAL WORKING INPUT VOLTAGE | 85-268V (AC) |
| INPUT VOLTAGE TO MAINTAIN HIGH PRECISION OUTPUT | 100-250V (AC) |
| OUTPUT VOLTAGE | AC 220V±5% 50/60Hz |
| DELAY TIME | Short Delay: 5sec Long Delay: 200sec |
| PROTECTION | Over Voltage, Under Voltage, Overload, High Temperature, Short Circuit |
| EFFICIENCY | >95% |
| PRODUCT SIZE (LxWxH) | 43.8×35.5×16.9 cm |
| PACKING SIZE | 49×40.5×21 cm |
| PCS/CARTON | 1 |
| N.W.(KGS) | 18.1 kg |
| G.W.(KGS) | 19.58 kg |
