STC-12KVA
STC-12KVA
Data Sheet Product
| MODEL | STC-12KVA |
| CAPACITY | 12 KVA |
| INPUT VOLTAGE | AC 95V-250V |
| ACTUAL WORKING INPUT VOLTAGE | 85-268V (AC) |
| INPUT VOLTAGE TO MAINTAIN HIGH PRECISION OUTPUT | 100-250V (AC) |
| OUTPUT VOLTAGE | AC 220V±5% 50/60Hz |
| DELAY TIME | Short Delay: 5sec Long Delay: 200sec |
| PROTECTION | Over Voltage, Under Voltage, Overload, High Temperature, Short Circuit |
| EFFICIENCY | >95% |
| PRODUCT SIZE (LxWxH) | 48.3×36.4×18.7 cm |
| PACKING SIZE | 54x40x26.1 cm |
| PCS/CARTON | 1 |
| N.W.(KGS) | 28.56 kg |
| G.W.(KGS) | 33.08 kg |
