NS70
NS70
Data Sheet Product
| Model No. | NS70Z |
| Nominal Voltage | 12V |
| Rated Capacity (20hr to 10.5V @ 25°C) | 65 Ah |
| Dimension | Length 258 mm Width 173 mm Height 200 mm Total Height 225 mm |
| Approx. Weight | 16.8 kg ± 3% |
| Charge Current (A) | 6.5 A (13.8V constant voltage charge) |
| Max. Charge Current | 19.5 A |
Electrical Specifications
| Capacity 25°C(77°F) | 20 hours rate (3.25 A to 10.5V) – 65 Ah 5 hours rate (12 A to 10.2V) – 53 Ah 1C (60 A to 9.6V) – 28 Ah 3C (180 A to 9.6V) – 21.5 Ah |
| Cold Cranking Amperes (-18°C) | 465 A |
| Operating Temperature Range | Charge – -40°C to 60°C
Discharge – -40°C to 60°C Storage – -15°C to 40°C |
| Best Use Temperature | 10°C to 30° |
| Max. Discharge Current | 650 A |
| Reserve Capacity | 100 min @ RC to 10.5 V @ 25°C |
| Charge Retention (self-discharge life at 20ºC (68°F) | 1 month = 92%
3 month = 90% 6 month = 80% |
| Warranty | 6 month |
| Case Material | PP |
