MPPT 60A
MPPT 60A
Data Sheet Product
| Model | MPPT 60 |
| Max. Charger Current | 60A |
| Systern Voltage | 12V/24V/48V |
| Max. PV Voltage (VOC) | 150 Vdc |
| Carton Dimension | 340 x 255 x 160 mm |
| Product Dimension | 260 x 220 x 110 mm |
| Product Weight | 3.2 kg |
| Operation Temperature | -25 ~60°C |
| Solar Operating Voltage | 20-150Vdc@12V 36-150Vdc@24V 64-150Vdc@48V |
| PV Input Power | 12V : 800W 24V : 1600W 48V : 3200W |
