MPPT 100A
MPPT 100A
Data Sheet Product
| MODEL | MPPT 100 |
| Max. Charger Current | 100A |
| Systern Voltage | 12V/24V/48V |
| Max. PV Voltage (VOC) | 200 Vdc |
| Carton Dimension | 415 x 311 x 173 mm |
| Product Dimension | 350 x 274 x 110 mm |
| Product Weight | 5.84 kg |
| Operation Temperature | -25 ~60°C |
| Solar Operating Voltage | 20-150Vdc@12V 36-150Vdc@24V 64-150Vdc@48V |
| PV Input Power | 12V : 1300W 24V : 2600W 48V : 5200W |
